BravePro Log Splitter | 24-Ton | Honda GX160

SKU: GNE-VH1724GX
Regular price $2,592.00
Free shipping
100% secure payments
Industry leading quality
  • Industrial I-beam construction provides incredible strength 4-stage hydraulic filtration system prevents contamination and damage to the hydraulic system Log cradle catches split logs and serves as a work table for large logs Heavy-duty log dislodger ejects stuck logs, protecting hydraulic components from damage Convenient lift handle for quicker, easier, and safer transitions between vertical and horizontal positions Sherwin-Williams powder coat paint withstands heavy use and weather elements Nylon hydraulic hose sleeve protects against abrasive wear, leaks, and sun damage Industrial cylinder with Halite seals keeps consistent pressure while splitting Tow-ready up to 45 MPH with 2" ball hitch, chains, and highway-rated tires

This BravePro 24-ton log splitter delivers ultimate splitting force in a strong, well-balanced package. Featuring a reliable Honda GX160 engine, you can easily split thick green logs with 24 tons of splitting pressure, offering commercial-grade features at a lower cost. Industrial I-beam construction provides incredible strength, while a 4-stage hydraulic filtration system with a suction strainer, breather cap air filter, return line filter, and magnetic drain plug prevents contamination and damage to the hydraulic system. Log cradles catch split logs and serve as a work table for large logs, and a heavy-duty log dislodger ejects logs that stick to the splitting wedge, protecting the control valve and other hydraulic components. A convenient lift handle provides added control for quicker, easier, and safer transitions between vertical and horizontal operating positions, and the industrial cylinder with Halite seals keeps consistent pressure while splitting. Tow-ready up to 45 MPH with a 2" ball hitch, chains, and highway-rated tires.

Equipment Type Log Splitter (Tow-Behind) Fenders No
Cycle Time 13 Seconds Fuel Capacity for Burner 0.83 Gal
Cylinder Size 4 in. Bore, 24 in. Stroke Hitch 2 in.
Dimensions 95 in. L x 44 in. W x 41 in. H Hydraulic Capacity 8 Gal
Displacement 163cc Log Cradle Yes
Dry Weight 500 lbs Log Diameter 16 in. Max
Engine GX160 Log Length 25 in. Max
Engine Brand Honda Operation Horizontal and Vertical
PSI 3500 Splitting Height 28 in.
Splitting Force 24 Tons Towing Speed 45 MPH
Wedge 8 in. High Carbon Steel

FREE SHIPPING, Liftgate service available for an additional fee at checkout.

Delivery in 10 - 15 Business Days

No separate warranty information listed for this product on the manufacturer page.

Frequently Asked Questions

How much splitting force does this log splitter produce?

It produces 24 tons of splitting force with a 13-second cycle time.

Can this log splitter be used both vertically and horizontally?

Yes, it operates in both horizontal and vertical positions, with a lift handle for safer, easier transitions between them.

What size logs can this splitter handle?

It splits logs up to 16" in diameter and 25" in length, with a maximum splitting height of 28".

What engine powers this log splitter?

It's powered by a Honda GX160 163cc engine.

Is this log splitter safe to tow?

Yes, it's tow-ready up to 45 MPH with a 2" ball hitch, chains, and highway-rated tires.

Does this come with hydraulic system protection?

Yes, it features a 4-stage hydraulic filtration system with a suction strainer, breather cap air filter, return line filter, and magnetic drain plug.

How much does this log splitter weigh?

It has a dry weight of 500 lbs.

Does it include fenders?

No, this model does not include fenders.
